Posts by alain_godard

alain_godard · viewer alain_godard September 9, 2024 at 9:05 PM

hello

with enable built-in web server, http://127.0.0.1:8086/app/ohif/

works correctly and finds the 17 studies present on the test pc.

Code

[CONQUESTSRV1] 09/09/24 20:30:34: Ladle web server v0.1.3 (c) 2008 S Saint-Pettersen (c) 2015 D Rempel
[CONQUESTSRV1] 09/09/24 20:30:34: Serving on *:8086
[CONQUESTSRV1] redirect /app/ohif/index.html
[CONQUESTSRV1] redirect /app/ohif/index.html
[CONQUESTSRV1] redirect /app/ohif/ohif1.03_min.js
[CONQUESTSRV1]
[CONQUESTSRV1] UPACS THREAD 723: STARTED AT: Mon Sep 09 20:31:12 2024
[CONQUESTSRV1]  Calling Application Title : "CONQUESTSRV1    "
[CONQUESTSRV1]  Called Application Title : "CONQUESTSRV1    "
[CONQUESTSRV1]  Application Context : "1.2.840.10008.3.1.1.1", PDU length: 32768
[CONQUESTSRV1]  Presentation Context 0 "1.2.840.10008.5.1.4.1.2.2.1" 1
[CONQUESTSRV1] (StudyRootQuery) search level: STUDY
[CONQUESTSRV1] C-Find (StudyRoot) located 17 records

Display More

To communicate with the server, I use wamps64 but in this case I have the message:

Code

[CONQUESTSRV1] 09/09/24 20:29:01: Ladle web server v0.1.3 (c) 2008 S Saint-Pettersen (c) 2015 D Rempel
[CONQUESTSRV1] 09/09/24 20:29:01: Failed to listen on given hostname:port, Ladle already running?

I wanted to use the ohiftop version in the hope of being able to do a jpg export of older series but no return:

http://localhost:8080/app/ohiftop/

app-config.js :

Code

window.config = {
  // default: '/'
  routerBasename: '/app/ohiftop/',
  extensions: [],
  showStudyList: true,
  filterQueryParam: false,
  disableServersCache: false,
  studyPrefetcher: {
    enabled: true,
    order: 'closest',
    displaySetCount: 3,
    preventCache: false,
    prefetchDisplaySetsTimeout: 300,
    maxNumPrefetchRequests: 100,
    displayProgress: true,
    includeActiveDisplaySet: true,
  },
  servers: {
    dicomWeb: [
      {
        name: 'dgate',
        wadoUriRoot: '/api/dicom/wadouri',
        qidoRoot: '/api/dicom/rs',
        wadoRoot: '/api/dicom/rs',
        qidoSupportsIncludeField: true,
        imageRendering: 'wadouri',
        thumbnailRendering: 'wadouri',
        enableStudyLazyLoad: true,
        supportsFuzzyMatching: true,
      },
    ],
  },
.......................

Display More

Sorry, my explanations are probably not very clear.

thanks for your help.

alain_godard · viewer alain_godard September 9, 2024 at 3:31 PM

Hi,

on my pc for testing:

C:\wamp64\www\api\dicom

Did I make a mistake?

PHP

<?php
  $exe  = 'dgate -p5678 -q127.0.0.1';
  $quote = '""';                // quotes in command line

  if (PHP_OS_FAMILY != 'Windows') {        // On Linux:
    $exe = './' . $exe;                // start as ./servertask
    $quote = '\"';                // quotes in command line
  }

  $userlogin = false;                // uses single file login system
  $wplogin   = false;                // uses wordpress login system

Display More

alain_godard · viewer alain_godard September 7, 2024 at 8:00 PM

I tried it but I arrive on a blank page for each viewer proposed. I just saw that I had the series if I did not use Firefox and yet, it was clearly specified in the manual....
On the other hand with wamp64, I have nothing even by changing to chrome or edge except for newweb.

I am still looking....

alain_godard · viewer alain_godard September 7, 2024 at 4:50 PM

Hello, I installed OHIF viewer as advised, but I couldn't connect dgate, while newweb works fine. I didn't find any help on the forum and I know that you don't maintain viewers. Where can I go?

Thank you.

Kind regards.

alain_godard · viewer alain_godard September 2, 2024 at 12:08 PM

Hello
I made the change to export the image in jpg but the transfer of SRs no longer worked. What is the correct syntax?

Code

# ImportConverters
ImportConverter0 = mkdir F:\Images\%i; save jpg to F:\Images\%i\%o.jpg

[lua]
ImportConverter9 = if Data.Modality=='SR' then Data:Write([[\\srv-maternite\workgroup$\mups\DicomTohPrimV2\dicom\]]..
Data.SOPInstanceUID .. '.dcm') end

Thanks

alain_godard · Conquest 1.5.0d released alain_godard September 1, 2024 at 9:11 AM

hello
With each new installation, I have to modify dicom.sql to integrate the line
" { 0x0010, 0x21d0, "LastMenstrualDate", 8, SQL_C_DATE, DT_DATE, "---" }, "
This is relevant information for pregnancy sonographers. Why is it not in the file?
Have a nice day.

alain_godard · viewer alain_godard August 31, 2024 at 5:24 AM

Hello
The first solution works perfectly in local testing, I will check that it does not overload the server excessively or set up an automatic deletion of folders in the shared directory older than 6 months.
I am installing version 1.5.0.d and I will get back to you if necessary.
Thanks again.
Kind regards.

alain_godard · viewer alain_godard August 30, 2024 at 10:54 AM

Good morning

I need your help to choose a viewer for ultrasound images saved in CONQUESTSRV1

Currently the viewer used is the serversideviewer.

C:\wamp\bin\apache\apache2.2.22\cgi-bin

viewer = serversideviewer

I need to be able to save the series of images in jpg format in a shared directory or print the series.

I see there are other viewers. which one would achieve this objective?

THANKS

alain_godard · failure importconverter alain_godard May 18, 2024 at 5:06 AM

Hi

on a fresh install I can't get ImportConverter to work

Code

[lua]
ImportConverter9 = if Data.Modality=='SR' then Data:Write([[\\192.xxx.xx.x\MedyCS$\mups\DicomTohPrimV2\dicom\]].. Data.SOPInstanceUID .. '.dcm') end

The file is not written to the remote directory.

I activated dicomserver Debug mode but I don't get any error messages.

Through Windows Explorer, I can create and modify a text file.

What could I be doing wrong?

THANKS.

alain_godard · CT cannot receive images alain_godard August 12, 2021 at 12:21 PM

Hello
I use DICOMSERVER150b and I have an image receiving error of a ultrasound.

[CONQUESTSRV1] A-ASSOCIATE-RQ Packet Dump

[CONQUESTSRV1] Calling Application Title : "Voluson "

[CONQUESTSRV1] Called Application Title : "CONQUESTSRV1 "

[CONQUESTSRV1] Application Context : "1.2.840.10008.3.1.1.1", PDU length: 28672

[CONQUESTSRV1] Number of Proposed Presentation Contexts: 6

[CONQUESTSRV1] Presentation Context 0 "1.2.840.10008.5.1.4.1.1.6.1" 1

[CONQUESTSRV1] Presentation Context 1 "1.2.840.10008.5.1.4.1.1.3.1" 1

[CONQUESTSRV1] Presentation Context 2 "1.2.840.10008.1.1" 1

[CONQUESTSRV1] Presentation Context 3 "1.2.840.10008.5.1.4.1.1.6" 1

[CONQUESTSRV1] Presentation Context 4 "1.2.840.10008.5.1.4.1.1.7" 1

[CONQUESTSRV1] Presentation Context 5 "1.2.840.10008.5.1.4.1.1.6.2" 1

[CONQUESTSRV1] Server Command := 0001

[CONQUESTSRV1] Message ID := 003b

[CONQUESTSRV1] FreeStore Left 100731 on f:\

[CONQUESTSRV1] Written file: f:\voluson\dicom_server\data\8001198657\1.2.276.0.26.1.1.1.2.2021.260.31579.3402772_0001_000021_16287579590027.dcm

[CONQUESTSRV1] UPACS THREAD 146: ENDED AT: Thu Aug 12 10:45:59 2021

[CONQUESTSRV1] UPACS THREAD 146: TOTAL RUNNING TIME: 0 SECONDS

[CONQUESTSRV1] ***No valid presentation contexts/transfer syntax found in 3 candidates

[CONQUESTSRV1] ***In 3 presentation contexts

[CONQUESTSRV1] ***#Possible transfer syntaxes: 1

[CONQUESTSRV1] *** multiplex: connection terminated

The other ultrasounds work properly.
What can I do ?
thank you

alain_godard · connect mysql MariaDB alain_godard July 19, 2021 at 9:19 PM

, It's perfect, thank you

alain_godard · connect mysql MariaDB alain_godard July 19, 2021 at 12:15 AM

Bonjour

cannot connect mysql on port 3306

Mariadb use port 3316

How to change the MySQL port in Dicom.Inid ?

thanks

alain_godard · copy files SR alain_godard April 11, 2021 at 4:58 PM

Hi,

definitely, I have gaps in syntax ...

That's perfect, thank you very much.

alain_godard · copy files SR alain_godard April 10, 2021 at 10:40 PM

Sorry

I'm doing it wrong and I have a syntax error.

dicom.ini :

[lua]

ImportConverter9 = if Data.Modality=='SR' then Data:Write(C:\dicomserver150b\structured_report\ Data.SOPInstanceUID .. '.dcm') end

message :

[CONQUESTSRV1] *** lua syntax error [string "if Data.Modality=='SR' then Data:Write(C:\dicomserver150b\struc..."]:1: '<name>' expected near '\' in 'if Data.Modality=='SR' then Data:Write(C:\dicomserver150b\structured_report\.. Data.SOPInstanceUID .. '.dcm') end'

alain_godard · copy files SR alain_godard April 10, 2021 at 5:08 PM

Hi,

I want to add an export in the dicom.ini copying the dicom SR file to a specific directory.

Thanks

alain_godard · SR files error alain_godard October 24, 2019 at 3:13 PM

hello, it's perfect. thank you

alain_godard · SR files error alain_godard October 18, 2019 at 8:33 PM

Hi,

no

alain_godard · SR files error alain_godard October 17, 2019 at 10:20 PM

Hi,

here is SAMSUNG's answer /

"Changing SR format on Conquest server.

- Can you contact and ask PACS engineer to change the SR format for Conquest server to "Explicit VR Little Endian"? "what change to make in the file dgatesop.lst ?

Merci

Alain

alain_godard · SR files error alain_godard September 19, 2019 at 8:16 PM

bonjour

Problem receiving files SR transmitted by écho SAMSUNG HS60. Error message:

[CONQUESTSRV1] ***No valid presentation contexts/transfer syntax found in 1 candidates

[CONQUESTSRV1] ***In 1 presentation contexts

[CONQUESTSRV1] ***#Possible transfer syntaxes: 1

[CONQUESTSRV1] *** multiplex: connection terminated

Worklist and the images work well.

Conquest Dicom server 1.4.19d1

Thanks

alain_godard

Oupss...
[Blocked Image: http://lagodardiere.free.fr/ecrans/dicom_2.png]
"Got error 127 from storage engine" when i use "DISTINCT" in your query.
