Ok,

the sql database automatically stores any non-sequence item that is listed in dicom.sql. You can maybe sort your problem by using lua to create private elements to the RTPLAN object and define these in dicom.sql so that they are written. However, as I pointed out there can be hundreds of control points so I am not sure how you would code that in a single text string. I think database fields in conquest are limited to 256 characters.

A better solution is to create a database table yourself (you can use lua to do this) and use lua sql() command to write into that and dbquery() to read.

console.bat runs a simple console where you can try any lua code. It stores the history of what you typed.

A bit of example code (from overview.lua in the distribution, it has examples for all lua functions):

sql("CREATE TABLE UserTable (CounterID varchar(99), Val integer)");

sql("INSERT INTO UserTable (CounterID,Val) VALUES ('CT',1) ON DUPLICATE KEY UPDATE Val=Val+1");

Marcel

Good,

You show that you read any information from a plan. Can you now explain what you actually want to achieve?

Marcel

ImportConverter0 = lua/yourfile.lua

use a / not a \

In your code line 10 misses a .

A simple way to test this code is in the GUI - modify image (advanced)

This is the correct syntax:

-- Enter Lua code to modify DICOM images here
-- E.g., Data.SeriesDescription = 'First series'
if Data.Modality=='RTPLAN' then
  print('Processing RTPLAN for patient Name ' .. Data.PatientName .. ' PatientID=' .. Data.PatientID);
  print('Date of RTPLAN is ' .. Data.RTPlanDate);

  local i
  for i=0, #Data.FractionGroupSequence-1 do
    for j=0,#Data.FractionGroupSequence[i].ReferencedBeamSequence-1 do
      if #Data.FractionGroupSequence[i].ReferencedBeamSequence[j].BeamMeterset>0 then
        print('MU ' ,i,j,#Data.FractionGroupSequence[i].ReferencedBeamSequence[j].BeamMeterset);
        print('NumberOfBeams ',i,j,#Data.FractionGroupSequence[i].ReferencedBeamSequence[j].NumberOfBeams);
      else
       print('MU for field ', i ,j,' is 0 or a nil value');
      end
    end
  end
end

Or install zerobrane studio and link it to conquest (see manual)

Marcel

BeamLimitingDeviceSequenc --> BeamLimitingDeviceSequence

ReferencedStructureSequenc -.> ReferencedStructureSequence

FractionGroupSequenc --> FractionGroupSequenc

Then the code may run. It should print info from the RTPLAN to the server's log window when it recieves one. The attached script shows an example script modifying tags in an rtlan. Use with care

Marcel

Hi,

you need to use the full names e.g. FractionGroupSequence

Marcel

Hi,

you can use Lua to read it, e.g. by starting a script for each received item:

ImportConverter0 = lua/yourfile.lua

And then e.g. there (this is for an RTSTRUCT, princliple is the same for an RTPLAN:

if Data.Modality=='RTSTRUCT' then

for i=0, #Data.StructureSetROISequence-1 do

print('*** frameofref', i, Data.StructureSetROISequence[i].ReferencedFrameOfReferenceUID)

end;

for i=0, #Data.ROIContourSequence-1 do

for j=0, #Data.ROIContourSequence[i].ContourSequence-1 do

for k=0, #Data.ROIContourSequence[i].ContourSequence[j].ContourImageSequence-1 do

print('*** r sop', i, j, k, Data.ROIContourSequence[i].ContourSequence[j].ContourImageSequence[k].ReferencedSOPInstanceUID)

end

end

end

end

Marcel

Hi, a radiation plan is an array of control points, that contain e.g. many gantry angles, leaf positions etc. So it is not possible to store these in a single database field. I also do not know what "modifyobject" means. And anyway anything in an exportconnverter runs after the image is stored in the database.

Marcel

Good idea Maarten, I will add to the wish list.

Marcel

great!

And what is the log in the recieving end?

Yes,

the changes are to support new database versions that do not like Rows or Columns as field name. Keep the old dicom.sql and you are fine.

Marcel

Then I think you should go for a nightly cleanup, rather than immediate.

Marcel

Hi,

prebuilt has only the sqlite driver. Best setup a test server somewhere and compile there. Then you can copy dgate to the old server's location. You also need to update lua scripts and webserver folder if you use those.

Marcel

I think retrying is the only thing that misses.

Marcel

Yeah importconverters are not retrying and block the sender (they are fast though). Cheers

Hi,

exportconverter is retrying in case of failure; so deletion is hard to schedule. Have you considered using an importconverter? That is immediate.

Marcel

Hi, any version supports it, just add sop classes to dgatesop.lst. Use a 64 bits version is recommended.

The prebuilt dgate in the current release is compiled on ubuntu14.04. So I guess it will compile on gcc 4.8.5. I have been careful not to use modern language feautures.

Marcel

Ok!

Ok,

I think there may be a space in the command_line you used - it must be empty otherwise its contents become patient_id. The log shows two space after Anonymized PatientID to:

Marcel

Hi,

you said "main PACS server to the test PACS server (conquest 1.15) no copying". Did you just try that? There is no error in the log.

Marcel
